FS-MINI Arcade Fight Stick
FS-MINI Arcade Fight Stick
Couldn't load pickup availability
Update: Middle frame will now have L3/R3 side buttons at no extra cost! If you would not like L3/R3 buttons and only want Start, Select, Home, Touchpad buttons, please contact me
3d Printed Mini fightstick, printed in PLA. Although they are pretty durable, they cannot stand high temperature (above ~130°F/~55°C) or it will start warping/melting. Try not to leave them in your car in a very hot day, but do reach out if you need replacements for anything!
If you would like me to do the artwork print and cutout for you, please add the Art Cutout listing in your order when you checkout and send me your design/art through discord, twitter, or the contact page from my website.
https://thetboxshop.com/products/fs-mini-acrylic-top-panel
This is designed to be used with low profile OSBMX 24mm buttons! Regular height 24mm buttons may not fit due to wiring restraints. Low profile Qanba Gravity KS buttons will fit, but wire management may be tight. Regular vertical prongs may need to be bended for guide and touchpad buttons on the middle frame.
- Choose between two different PCBs: GP2040 (PC, PS4, Switch) + PS5 Adapter (only fighting games) or Brook Gen5x (PC, PS5, Xbox S/, Switch)
- Heat set brass inserts for ease of assembly and disassembly
- SOCD Modes: Neutral, Last Priority, or Up Priority
- Choose between Basic or Art versions: Basic will have no acrylic on top, Art will have Acrylic
- Uses 24mm OSBMX low profile buttons
- Choose between silent or regular linear switches. Currently, switches are Akko Silver Pro v3 and Outemu Silent Peach v3.
- Panel mounted USB C input connection
- Many colors to choose from! Please see attached photo for color options of buttons, Top panel, bottom panel, middle frame.
- Qanba Gravity Silent joystick will be installed when choosing silent option
- Sanwa JLX-TP-8YT-SK joystick will be installed when choosing linear option
- Dimensions: 250 x 150 x 42mm
GEN-5X Specification and Instruction Manual
PSD template for artwork can be found here:
https://drive.google.com/file/d/10aq1kYvwT2t5BjjoIFTuSyYPQavh0Gxe/view?usp=drive_link
This is a heavily remixed design by me, Remixed from gp2040 open stick :
https://github.com/OpenStickCommunity/Hardware/tree/main/3D%20Prints/Fightstick%20Case
